Installing Microsoft® Windows PowerShell Extensions for Microsoft SQL Server 2016 (AKA sqlps)

The PowerShell modules (aka sqlps) are installed by default when installing Microsoft SQL Server.

You can manually install the PowerShell Extensions for SQL Server 2016 by installing the following components from the Microsoft® SQL Server® 2016 Feature Pack:

  1. Microsoft® System CLR Types for Microsoft SQL Server® 2016 (SQLSysClrTypes.msi)
  2. Microsoft® SQL Server® 2016 Shared Management Objects (SharedManagementObjects.msi)
  3. Microsoft® Windows PowerShell Extensions for Microsoft SQL Server® 2016 (PowerShellTools.msi)

sqlps-install-list

Check if the module has been successfully installed:

# Import the SQL Server Module.
Import-Module Sqlps -DisableNameChecking

# To check whether the module is installed.
Get-Module -ListAvailable -Name Sqlps

Check-out the official complete guide SQL Server PowerShell.

Advertisements

Getting Started with Azure PowerShell (Classic)

Thanks to opsgility (original post).

For the new AzureRM (resource manager model) please check the official: Get started with Azure PowerShell cmdlets.

Download the Azure PowerShell Cmdlets

Windows install that you can also found at Microsoft Azure Downloads

Configure your Azure Subscription with the Azure PowerShell Cmdlets.

The simplest way to access your Azure subscription from PowerShell is to use the Add-AzureAccount cmdlet.

Add-AzureAccount

After executing the cmdlet a dialog will appear to prompt you to login with your Microsoft or Organization account. After you login, you will have access for 12 hours before you have to login again.

Enumerating and selecting a subscription

You can use the PowerShell cmdlets to enumerate and view your current subscription settings.
Here are some of the more handy ones to know about:

# Enumerates all configured subscriptions on your local machine.
Get-AzureSubscription

# Returns details only on the specified subscription
Get-AzureSubscription -SubscriptionName "mysubscription"

# Select the subscription to use
Select-AzureSubscription -SubscriptionName "mysubscription"

# Sets the mysub subscription to be the default if one is not selected.
Set-AzureSubscription -DefaultSubscription "mysub"

CONFIGURING STORAGE WITH THE CURRENTSTORAGEACCOUNT PARAMETER

When using the WA Cmdlets with Virtual Machines (IaaS) or Cloud Services (PaaS) you will need to specify the CurrentStorageAccount for your subscription. This is basically the storage account that will be used for creating VHDs or uploading .cspkg files. For virtual machines this storage account has to be in the same datacenter that you plan on creating virtual machines in.

Set-AzureSubscription -SubscriptionName "mysub" -CurrentStorageAccount "mystorageaccount"

To discover if you have a storage account or create a new storage account from PowerShell:

# Discover whether you have a storage account already
Get-AzureStorageAccount

# Creates a new storage account in the West Europe data center
New-AzureStorageAcount -StorageAccountName "mystorageaccountname" -Location "West Europe"

Which of course begs the question – how do I know which data centers are available?

The following cmdlet will give you that information:

Get-AzureLocation

This is everything you need to configure the Azure PowerShell cmdlets for your subscription!

Performance best practices for SQL Server in Azure Virtual Machines (link to resources)

How to create striped disk on azure (AKA Raid 0)

Disk Striping use multiple disks and stripe them together to get a combined higher IOPS and Throughput limit. Note that the combined limit per VM should be higher than the combined limits of attached premium disks.

You can check the maximum number of disks you can add to a virtual machine from here: Sizes for Windows virtual machines in Azure

1. Create “new disk” from powershell:

clear

# RM stands for resource manager, and is the new way of managing things in Azure

# you need to login the first time using this command
# Login-AzureRmAccount

$vm = Get-AzureRmVM -ResourceGroupName "md-test-stripe" -Name "md-test-stripe"

# adds 16 disks
for($i=1; $i -le 16; $i++) {
    $name = "md-test-stripe-disk{0:00}" -f $i
    $lun = $i - 1
    $vhdUri = "https://mdteststripedisks447.blob.core.windows.net/vhds/md-test-stripe-disk{0:00}.vhd" -f $i

    Write-Host "Add-AzureRmVMDataDisk -VM $vm -Name $name -DiskSizeInGB 16 -Lun $lun -Caching None -VhdUri $vhdUri -CreateOption Empty"

    $vm = Add-AzureRmVMDataDisk -VM $vm -Name $name -DiskSizeInGB 16 -Lun $lun -Caching None -VhdUri $vhdUri -CreateOption Empty
}

$vm.DataDiskNames

# uncomment when you are ready, this updates the VM on azure!
# Update-AzureRmVM -ResourceGroupName "md-test-stripe" -VM $vm

2. Create “new storage pool” from server manager with all the new disks you added

3. Create “new virtual disk” from powershell:

New-VirtualDisk -FriendlyName "sql-stripe" -StoragePoolFriendlyName "sql-stripe" -Interleave 65536 -NumberOfColumns 16 -ProvisioningType Fixed -ResiliencySettingName "Simple" -UseMaximumSize

4. Create “new volume” from server manager formatting in NTFS with allocation unit size set to 64KB

Porting from SQLIO to DISKSPD: How to Test Disk Performance for SQL Server

DISKSPD TESTS

Original post related to SQLIO took from brentozar blog.

diskspd -w100 -t8 -d60 -o32 -r -b8K -Sh -L -c20G C:\test.dat
diskspd -w0 -t8 -d60 -o32 -r -b8K -Sh -L -c20G C:\test.dat
diskspd -w100 -t8 -d60 -o32 -si -b64K -Sh -L -c20G C:\test.dat
diskspd -w0 -t8 -d60 -o32 -si -b64K -Sh -L -c20G C:\test.dat

What Do the DISKSPD Parameters Mean?

While we’re looking at that set of commands, here’s a quick breakdown:

  • -w100 and -w0: means we’re testing writes (100% writes) or reads (0% writes).
  • -t8 and -o32: means 8 threads with up to 32 outstanding requests at once.
    DISKSPD isn’t CPU-bound at all, and you can use more threads than you have processors.
    The more load we throw at storage, the faster it goes – to a point.
  • -d60: means the test will last 60 seconds
  • -b8K and -b64K: the size of our IO requests in kilobytes.
    SQL Server does a lot of random stuff in 8KB chunks,
    and we’re also testing sequential stuff in 64KB chunks.
  • -r and -s: random versus sequential access.
    Many queries jump around randomly in the database, whereas things like backups,
    bulk loads, and table scans generally work sequentially.
  • -L: measure latency statistics.
  • -Sh: equivalent -Suw, disable software caching, equivalent to FILE_FLAG_NO_BUFFERING and enable writethrough (no hardware write caching), equivalent to FILE_FLAG_WRITE_THROUGH.
  • -c20G: create a file of 20GB. Size can be stated in bytes or KiB/MiB/GiB/blocks.

You’ll notice I’m using a lot of general terms here about how some application patterns work.
Every SQL Server database has its own access patterns – random, sequential, big chunks, small pieces, and so on.
The four test lines you see above are shorthand examples of how some SQL Server IO patterns work.
We’re going to run a quick 4-part test first, and then come back to run much more in-depth tests shortly.

Powershell Commands for Visual Studio Team Services (VSTS, AKA VSO)

For instance you can set a variable like this:

Examples:

##vsotask.setvariable variable=testvar;]testvalue
##vso[task.setvariable variable=testvar;issecret=true;]testvalue

in powershell:

Write-Host "##vso[task.setvariable variable=testvar;]testvalue"

Here’s the complete list:

https://github.com/Microsoft/vsts-tasks/blob/master/docs/authoring/commands.md

Happy scripting!

How to Debug the Design Time Errors in WPF XAML File?

[Reblogged from How to Debug the Design Time Errors in WPF XAML File? thanks to Manish Dubeyy]

Introduction

While developing WPF applications, design view plays an important role not only placing the controls but also we can see the run time view at design time. How does it look like? It becomes frustrating when we see some design time errors and we cannot put a break point in XAML file to diagnose the error, moreover due to this single error sometimes, whole designer fails rendering other controls. So this article enables us to debug the design view of XAML documents in WPF.

Background

It is a pre-requisite that one should be familiar with basic WPF and most importantly one should know how to set design time data context. You can refer to other articles on CodeProject to know how to set a design time data context like this one.

Problem

While designing WPF applications, we frequently see the following types of error in our design view (See pic). Since XAML code does not allow us to insert a break point and debug the stuff, I will share a small trick to trap this error. (References are already there on the internet, but still developers are not so habituated to using it. The reason is that most of them don’t know it.)

ErrorPreview

Steps To Debug the Design Time Errors

  1. First of all, close all opened XAML documents in Visual Studio.
  2. Open the new instance of the same application in Visual Studio (say app2).
  3. Again, close all opened XAML documents. (To be on the safe side, you may close all documents in app2).
  4. Now open Task Manager just to verify whether XDesProc.exe must not be running. (Basically XDesProc.exeis responsible for debugging XAML files, so if any XAML documents are opened, then it launches automatically). So, if you find that XDesProc.exe is running (in Processes Tab), just kill it (right click on process and click on End Process Tree option).
  5. Now switch to app1 (original instance of Visual Studio in which you want break point to be hit). Now, open the file containing the design data view model (MainWindowViewModelDesignData.cs) and place a break point in the first line of its constructor.
  6. Switch to app2 again and open the View (i.e. MainWindow.xaml in which design time error is raising). It will launch the XDesProc.exe in Task Manager.
  7. Switch to app1 again, and go to Debug -> Attach to Processes… context menu item in Menu bar of Visual Studio.
  8. Search the XDesProc.exe and click on attach button.
  9. Switch to app2 and close and reopen the same XAML document (MainWindow.xaml). Once you do it, break point will get hit!2-Solve
  10. Here, you will find that you have not instantiated the PersonList property which is causingNullReference Exception in WPF Designer. After fixing it, you will see that now the designer is showing the data as well.3-DesignView

Points of Interest

For Visual Studio 2010 users, you will find devenv.exe in place of XDesProc.exe. Also, you can tweak with the exception settings if your break point does not becomes active (i.e., Go to Debug -> Exceptions settings -> Common Language RunTime Exceptions).
